A Guide In Firefox to New And Creative CSS DevTools

Over the last few years, our team at Firefox has been operating on new CSS gear that address both cutting-edge strategies and age-old frustrations. We’re the Layout Tools team, a subset of Firefox Developer Tools, and our quest is to improve the modern-day internet layout workflow.

The internet has seen an first-rate evolution inside the final decade: new HTML/CSS functions, browser improvements, and design strategies. Our crew is dedicated to constructing gear that fit that innovation so that designers and developers can harness extra of the performance and creativity that’s now possible.

In this guide, we’ll proportion a top level view of our seven new equipment, with memories from the design system and realistic steps for trying out each tool.

1. Grid Inspector

It all started out three years in the past while our CSS format expert and dev advocate, Jen Simmons, labored with members of Firefox DevTools to construct a device that would aid customers in examining CSS Grid layouts.

As one of the most powerful new functions of the cutting-edge internet, CSS Grid had quick gained decent browser adoption, but it still had low internet site adoption. There’s a steep studying curve, and you nevertheless need fallbacks for sure browsers. Thus, part of our purpose turned into to help popularize Grid by way of giving developers a more hands-on manner to research it.

The middle of the device is a grid outline, overlaid at the page, which facilitates devs visualize how the grid is positioning their elements, and the way the layout modifications once they tweak their styles. We introduced numbered labels to identify each grid line, the capability to view up to 3 grids at once, and colour customization for the overlays. Recently, we also introduced support for subgrid, a modern day CSS specification implemented in Firefox and hopefully in extra browsers soon.

Grid Inspector changed into an idea for all of the tools that followed. It was even an notion for a brand new team: Layout Tools! Formed in late 2017, we’re unfold across 4 time zones and collaborate with many others in Mozilla, like our rendering engine builders and the best parents at MDN.


In Firefox, go to our Grid example site.

Open the Inspector with Cmd + Shift + C.

Turn on Grid overlay through one of 3 ways:

Layout Panel:

In the Grid section, check the checkbox subsequent to .Content.Grid-content;

Markup View:

Toggle the “grid” badge next to ;

Rules View:

Click the button next to display:grid; inside #page-intro .Grid-content;

Experiment with the Grid Inspector:

Change the crimson overlay coloration to red;

Toggle “Line numbers” or “Extend strains infinitely”;

Turn on greater grid overlays;

See what takes place while you disable grid-gap: 15px in Rules.

2. The Editor of Form Path

The next project we have been working on has been the Shape Path Editor: our first visual editing tool.

CSS Shapes permits you to define shapes for textual content to drift around: a circle, a triangle, or a many-sided polygon. It can be used with the clip-path assets which permits you to trim elements to any of those equal shapes. These two techniques collectively open the opportunity for a few very specific graphic design-stimulated layouts.

However, creating these sometimes complicated shapes can be difficult. Typing all the coordinates manually and the use of the right CSS units is error-inclined and some distance eliminated from the creative mind-set that Shapes allows. Therefore, we made a device that allows you to edit your code through at once clicking and dragging shapes on the web page.

This kind of feature—visible editing—became new for us and browser tools in general. It’s an instance of how we will go beyond inspecting and debugging and into the world of design.


In Firefox, go to this web page at the An Event Apart website.

Open the Inspector with Cmd + Shift + C and pick out the first circular image.

In Rules, click on the icon subsequent to the shape-outside property.

On the web page, click on the factors of the shape and notice what happens while you drag to make the shape massive or tiny. Change it to a size that appears exact to you.

3. Text Reader

We have had a Fonts panel in Firefox for years which displays an informative list of all the fonts used in a website. We decided to convert this into a Font Editor to fine-tune the properties of a font by continuing our trend of designing in the browser.

A driving force behind this assignment become our purpose to support Variable Fonts at the same time that the Firefox rendering engine team changed into adding support for it. Variable Fonts gives font designers a way to offer fine-grained variations alongside axes, like weight, within one font file. It also supports custom axes, which offer each font creators and web designers an exceptional amount of flexibility. Our device routinely detects these custom axes and offers you a manner to alter and visualize them. This would otherwise require specialized websites like Axis-Praxis.

Additionally, we added a characteristic that gives the ability to hover over a font name to spotlight in which that particular font is being used at the page. This is helpful because the manner browsers select the font used to render a bit of text can be complex and depend upon one’s computer. Some characters may be abruptly swapped out for a special font due to font subsetting.


In Firefox, go to this variable fonts demo site.

Open the Inspector with Cmd + Shift + C and pick out the word “variable” within the title (the element’s selector is .Title__variable-web__variable).

In the 1/3 pane of the Inspector, navigate to the Fonts panel:

Hover over the font name Output Sans Regular to look what receives highlighted;

Try out the load and slant sliders;

Take a take a look at the preset font versions within the Instances dropdown menu.

4. Flexbox Inspector

Our Grid, Shapes, and Variable Fonts equipment can together electricity some very advanced graphic layout at the internet, but they’re still somewhat present day based on browser support. (They’re nearly there, however still require fallbacks.) We didn’t need to work most effective on new features—we were drawn to the problems that maximum web builders face on a every day basis.

So we started work at the Flexbox Inspector. Design-wise, this has been our most ambitious assignment, and it sprouted some new consumer research strategies for our team.

Like Grid, CSS Flexbox has a fairly steep learning curve while you first get started. It takes time to truely recognize it, and a lot of us hotel to trial and error to gain the layouts we need. At the beginning of the assignment, our team wasn’t even sure if we understood Flexbox ourselves, and we didn’t recognize what the main challenges have been. So we leveled up our understanding, and we ran a survey to discover what human beings wanted the most when it got here to Flexbox.

The outcomes had a big effect on our plans, making the case for complicated visualizations like grow/decrease and min/max. We continued operating with the community at some point of the task by means of incorporating remarks into evolving visual prototypes and Nightly builds.

The tool consists of two main parts: a highlighter that works just like the Grid Inspector’s, and a detailed Flexbox device inside the Inspector. The middle of the tool is a flex item diagram with sizing info.

With help from Gecko format engineers, we have been able to show the step-by-step size choices of the rendering engine to offer users a full image of why and the way a flex object ended up with a positive size.

Note: Learn the full tale of our design manner in “Designing the Flexbox Inspector”.


In Firefox, visit Mozilla’s Bugzilla.

Open the Inspector with Cmd + Shift + C and pick out the element div.Inner (simply inside the header bar).

Turn on the Flexbox overlay through one of 3 ways:

Layout Panel:

In the Flex Container section, turn on the switch;

Markup View:

Toggle the “flex” badge next to ;

Rules View:

Click the button next to display:flex.

Use the Flex Container panel to navigate to a Flex Item known as nav#header-nav.

Note the sizes shown within the diagram and length chart;

Increase and reduce your browser’s width and see how the diagram modifications.

Interlude: Doubling Down On Research

As a small team and not using a formal person research support, we’ve regularly resorted to design-by-dogfooding: basing our critiques on our personal stories in using the tools. But after our achievement with the Flexbox survey, we knew we wanted to be better at collecting statistics to guide us. We ran a new survey to assist tell our subsequent steps.

We crowdsourced a list of the 20 largest demanding situations faced by internet devs and asked our community to rank them using a max-diff format.

When we discovered that the huge winner of the demanding situations was CSS Layout Debugging, we ran a follow-up survey on unique CSS insects to discover the largest pain points. We supplemented these surveys with user interviews and user testing.

We also asked folks to rank their frustrations with browser developer tools. The clear pinnacle difficulty became moving CSS modifications returned to the editor. This became our subsequent project.

5. Changes Panel

The difficulty in shifting one’s work from a browser developer device to the editor is one of those age-old issues that we all just got used to. We were excited to make a easy and straight away usable solution.

Edge and Chrome DevTools got here out with versions of this device first. Ours is centered on assisting a wide range of CSS workflows: Launch DevTools, trade any patterns you want, and then export your modifications by means of either copying the overall set of changes (for collaboration) or simply one changed rule (for pasting into code).

This improves the robustness of the whole workflow, such as our other format tools. And this is just a start: We recognize accidental refreshing and navigation from the web page is a huge source of facts loss, so a manner to bring persistence to the tool may be an essential next step.


In Firefox, navigate to any website.

Open the Inspector with Cmd + Shift + C and pick an element.

Make some adjustments to the CSS:

Modify patterns inside the Rules pane;

Adjust fonts within the Fonts pane.

In the right pane of the Inspector, navigate to the Changes tab and do the following:

Click Copy All Changes, then paste it in a text editor to view the output;

Hover over the selector name and click Copy Rule, then paste it to view the output.

6. Inactive CSS

Our Inactive CSS feature solves one of the top troubles from our layout debugging survey on precise CSS bugs:

“Why is this CSS assets now not doing anything?”

Design-wise, this feature is very simple—it grays out CSS that doesn’t affect the page, and shows a tooltip to give an explanation for why the property doesn’t have an effect. But we understand this can enhance efficiency and cut down on frustration. We have been bolstered by research from Sarah Lim and her colleagues who constructed a similar device. In their studies, they observed that novice builders had been 50�ster at building with CSS when they used a device that allowed them to ignore beside the point code.

In a way, that is our favorite sort of feature: A low-placing UX fruit that barely registers as a feature, however improves the complete workflow without actually wanting to be determined or learned.

Inactive CSS launches in Firefox 70 but may be used now in prerelease variations of Firefox, consisting of Developer Edition, Beta, and Nightly.


Download Firefox Developer Edition;

Open Firefox and navigate to wikipedia.Org;

Open the Inspector with Cmd + Shift + C and choose the center content material area, called central-featured;

Note the grayed out vertical-align declaration;

Hover over the data icon, and click on “Learn extra” if you’re interested.

7. Accessibility Panel

Along the way we’ve had accessibility functions developed by means of a separate group that’s typically one person — Yura Zenevich, this year together with his intern Maliha Islam.

Together they’ve turned the brand new Accessibility panel in Firefox into a powerful inspection and auditing tool. Besides displaying the accessibility tree and properties, you could now run different varieties of checks on a page. So far the checks include shade contrast, textual content labels, and keyboard attention styling.

Now in Nightly, you can strive the new shade blindness simulator which harnesses our upcoming WebRender tech.


Download Firefox Developer Edition;

Navigate to meetup.Com;

In the developer tools, navigate to the Accessibility tab, and click the “Turn on Accessibility Features” button;

Click the drop-down menu subsequent to “Check for problems” and pick out “All Issues”;

Take a have a look at the diverse contrast, keyboard, and text label troubles, and click the “Learn greater” links if you’re interested.

Next Up

We’re currently hard at paintings on a browser compatibility tool that uses facts from MDN to expose browser-specific problems for a particular element. You can follow along on GitHub to learn extra.

The Future

We’re committed to helping the modern-day web, and that means continuously converting and growing.

New specs get implemented via browser vendors all of the time. Guidelines and nice practices around progressive enhancement, responsiveness, and accessibility evolve constantly. Us device makers need to hold evolving too.

And what of the long-lived, ever-present troubles in creating the web? What ordinary user interfaces need to be rethought? These are a number of the questions that preserve us going!

What approximately a better manner to navigate the DOM tree of a page? That a part of DevTools has gone essentially unchanged since the Firebug days.

We’ve been experimenting with functions like again and forward buttons that might ease navigation between lately visited elements.

A extra dramatic trade we’re discussing is including a compact DOM view that makes use of a syntax much like HTML templating engines. The attention could be on the most common use case—navigating to CSS—as opposed to viewing/enhancing the source.

We’ve additionally been thinking about a higher element selector. We realize how it can be more effective to work inside the web page, with much less jumping backward and forward into DevTools. We should make the detail selector extra effective and greater persistent. Perhaps it could choose whitespace on a page and tell you what causes that space, or it can shed mild at the relationships between extraordinary elements.
